Synology RackStation RS820RP+ (4-Bay NAS)

Synology RackStation RS820RP+ (4-Bay NAS) [RS820RP+] Εικόνα 1 Synology RackStation RS820RP+ (4-Bay NAS) [RS820RP+] Εικόνα 2 Synology RackStation RS820RP+ (4-Bay NAS) [RS820RP+] Εικόνα 3
Εξαντλημένο
-
Χωρίς ΦΠΑ: - €
Πληροφορίες
Κωδικός Msystems: 001-45802
Part Number: RS820RP+
Εγγύηση: 3 Έτη

Παρακαλώ συμπληρώστε τον ΤΚ σας
Παρακαλώ επιλέξτε νομό
Παρακαλώ επιλέξτε πόλη

Με πιστωτική κάρτα Visa, Mastercard, American Express, Diners
Παρακάτω βλέπετε τις επιλογές για τις έντοκες δόσεις. για άτοκες δόσεις πρέπει το συνολικό ποσό της παραγγελίας σας να ξεπερνά τα 200€
759,40 € / δόση = 1.518,80 €
508,57 € / δόση = 1.525,70 €
383,12 € / δόση = 1.532,46 €
307,84 € / δόση = 1.539,22 €
257,69 € / δόση = 1.546,12 €
221,86 € / δόση = 1.553,03 €
194,99 € / δόση = 1.559,93 €
174,09 € / δόση = 1.566,84 €
157,37 € / δόση = 1.573,74 €
143,71 € / δόση = 1.580,79 €
132,32 € / δόση = 1.587,84 €
122,68 € / δόση = 1.594,89 €
114,42 € / δόση = 1.601,94 €
107,27 € / δόση = 1.609,00 €
101,01 € / δόση = 1.616,19 €
95,49 € / δόση = 1.623,39 €
90,59 € / δόση = 1.630,59 €
86,20 € / δόση = 1.637,79 €
82,26 € / δόση = 1.645,13 €
78,68 € / δόση = 1.652,33 €
75,44 € / δόση = 1.659,68 €
72,48 € / δόση = 1.667,02 €
69,77 € / δόση = 1.674,37 €
67,27 € / δόση = 1.681,86 €
64,97 € / δόση = 1.689,20 €
62,84 € / δόση = 1.696,70 €
60,86 € / δόση = 1.704,19 €
59,03 € / δόση = 1.711,83 €
57,31 € / δόση = 1.719,32 €
55,71 € / δόση = 1.726,96 €
54,21 € / δόση = 1.734,60 €
52,79 € / δόση = 1.742,23 €
51,47 € / δόση = 1.749,87 €
50,22 € / δόση = 1.757,66 €
49,04 € / δόση = 1.765,44 €

Με πιστωτική κάρτα Visa, Mastercard
Δεν υπάρχει η δυνατότητα για άτοκες δόσεις με κάρτες American Express και Diners
734,50 € / δόση = 1.469,00 €
489,67 € / δόση = 1.469,00 €
367,25 € / δόση = 1.469,00 €
293,80 € / δόση = 1.469,00 €
244,83 € / δόση = 1.469,00 €

Δόσεις χωρίς πιστωτική μέσω tbi bank
Πραγματοποιήστε τις αγορές σας, για ποσά από 300€ έως 10.000€, σε έως 60 μηνιαίες δόσεις χωρίς χρήση πιστωτικής κάρτας
Facebook Twitter Email
Facebook Twitter Email
Περιγραφή

High-performance storage solution with on-demand scalability

Synology RackStation RS820RP+ is designed for businesses pursuing an effective and centralized data management. It comes with four drive trays and 1GbE LAN ports and supports an optional 10GbE network or M.2 SSD adapter card, providing fast data transmission and reducing IO latency.

CPU

4-core 2.1 GHz

Memory

2GB DDR4, up to 18GB

High Performance

Over 1,621 MB/s sequential reading

Scalability

Up to 8 drives with RX418

Built for service reliability

RS820RP+ comes with four 1GbE LAN ports to support Link Aggregation and failover. Synology High Availability provides a reliable active/passive server cluster, maximizing service uptime. Furthermore, RS820RP+ is equipped with redundant power supplies to achieve service continuity.

  1. Power indicator
  2. Power button
  3. Alert indicator
  4. Drive status indicator
  5. Beep off button
  6. Status indicator
  7. Drive tray
  8. Console port
  9. PCIe expansion slot
  10. Power port
  11. System fan
  12. 1GbE RJ-45 port
  13. Reset button
  14. USB 3.0 port
  15. eSATA port





Hardware Specifications
CPU
CPU Model Intel Atom C3538
CPU Quantity 1
CPU Architecture 64-bit
CPU Frequency 4-core 2.1 GHz
Hardware Encryption Engine (AES-NI) Yes
Memory
System Memory 2 GB DDR4 non-ECC
Total Memory Slots 1
Maximum Memory Capacity 18 GB (2GB + 16 GB)
Notes Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Drive Bays 4
Maximum Drive Bays with Expansion Unit 8 (RX418 x 1)
Compatible Drive Type 3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Single Volume Size* 108 TB
Hot Swappable Drive Yes
Notes "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
Each internal volume (may consist of multiple drives) is expandable up to 108TB.
External Ports
RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
USB 3.0 Port 2
eSATA Port 1
PCIe
PCIe Expansion 1 x Gen3 x8 slot (black, x4 link)
File System
Internal Drives Btrfs
EXT4
External Drives Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Form Factor (RU) 1U
Size (Height x Width x Depth) 44 mm x 480 mm x 518.6 mm
Weight 7.96 kg
Rack Installation Support 4-post 19" rack (Synology Rail Kit - RKM114/RKS1317)
Notes The rail kit is sold separately
Others
System Fan 40 mm x 40 mm x 2 pcs
Fan Speed Mode Full-Speed Mode
Cool Mode
Quiet Mode
Power Recovery Yes
Noise Level* 39.9 dB(A)
Scheduled Power On / Off Yes
Wake on LAN / WAN Yes
Power Supply Unit / Adapter 150 W
Redundant Power Supply yes
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 38.88 W (Access)
22.17 W (HDD Hibernation)
British Thermal Unit 132.75 BTU/hr (Access)
75.70 BTU/hr (HDD Hibernation)
Notes Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification FCC, CE, BSMI, EAC, CCC, KC, VCCI, RCM
Environment RoHS Compliant
Packaging Content Main Unit X 1, Accessory Pack X 1, AC Power Cord X 1, AC Power Cord X 2 (for RP model), Quick Installation Guide X 1
DSM Specifications
Storage Management
Maximum Internal Volume Number 64
SSD Read / Write Cache  Yes
SSD TRIM Yes
Supported RAID Type Synology Hybrid RAID
Basic
JBOD
RAID 0
RAID 1
RAID 5
RAID 6
RAID 10
RAID Migration Basic to RAID 1
Basic to RAID 5
RAID 1 to RAID 5
RAID 5 to RAID 6
Volume Expansion with Larger HDDs Synology Hybrid RAID
RAID 1
RAID 5
RAID 6
RAID 10
Volume Expansion by Adding a HDD Synology Hybrid RAID
JBOD
RAID 5
RAID 6 (with Expansion Unit)
Global Hot Spare Supported RAID Type Synology Hybrid RAID
RAID 1
RAID 5
RAID 6 (with Expansion Unit)
RAID 10 (with Expansion Unit)
File Services
File Protocol CIFS / AFP / NFS / FTP / WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections 500
Maximum Concurrent CIFS/AFP/FTP Connections (with RAM expansion) 2,000
Windows Access Control List (ACL) Integration Yes
NFS Kerberos Authentication Yes
Notes Regarding data concerning tests with RAM expansion, all memory slots are installed with the maximum capacity of supported RAM.
Account & Shared Folder
Maximum Local User Accounts 2,048
Maximum Local Groups 256
Maximum Shared Folder 512
Maximum Shared Folder Sync Tasks 8
High Availability Synology High Availability
Log Center
Syslog Events per Second 800
Virtualization
VMware vSphere 6 with VAAI Yes
Windows Server 2016 Yes
Windows Server 2019 Yes
Citrix Ready Yes
OpenStack Yes
General Specifications
Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers Google Chrome
Firefox
Microsoft Edge
Internet Explorer 10 onwards
Safari 10 onwards
Safari (iOS 10 onwards)
Google Chrome (Android 6.0 onwards)
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Add-on Packages
Antivirus by McAfee (Trial) yes
Central Management System Yes
Synology Chat
Maximum Users 1,500
Notes The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
CPU and RAM usage were both under 80% when the number of maximum users was reached.
For tested models with expandable memory, the maximum amount of RAM was installed.
Document Viewer Yes
Download Station Yes
Maximum Concurrent Download Tasks 80
exFAT Access (Optional) Yes
iSCSI Manager
Maximum iSCSI Target Number 128
Maximum iSCSI LUN 256
iSCSI LUN Clone/Snapshot, Windows ODX Yes
Synology MailPlus / MailPlus Server
Free Email Accounts 5 (Licenses required for additional accounts)
Maximum Number of Concurrent Users 150
Maximum Server Performance 1,484,000 emails per day, approx. 45GB
Notes The CPU and RAM usage were both under 80% when testing the maximum number of concurrent users.
Models with more than 4 bays were installed with two SSDs for SSD cache.
For tested models with expandable memory, the maximum amount of RAM was installed.
The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).
Media Server
DLNA Compliance Yes
Moments
Facial Recognition Yes
Subject Recognition Yes
Auto Color & Rotate Yes
Moments Select Yes
Snapshot Replication
Maximum Snapshots per Shared Folder 1,024
Maximum of System Snapshots 65,536
Surveillance Station
Maximum IP cam (Licenses required) 40 (including 2 Free License)
Total FPS (H.264) 1200 FPS @ 720p (1280x720)
800 FPS @ 1080p (1920x1080)
340 FPS @ 3M (2048x1536)
240 FPS @ 5M (2591x1944)
120 FPS @ 4K (3840x2160)
Total FPS (H.265) 1200 FPS @ 720p (1280x720)
1200 FPS @ 1080p (1920x1080)
880 FPS @ 3M (2048x1536)
480 FPS @ 5M (2591x1944)
280 FPS @ 4K (3840x2160)
Total FPS (MJPEG) 380 FPS @ 720p (1280x720)
250 FPS @ 1080p (1920x1080)
190 FPS @ 3M (2048x1536)
140 FPS @ 5M (2591x1944)
Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
The maximum channel number also includes devices installed on Virtual DSM.
Total FPS may be affected by other services running at the same time (e.g., archive tasks performed by Archive Vault).
Synology Drive
Recommended Number of Hosted Files 1,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Sync Clients 550 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
For tested models with expandable memory, the maximum amount of RAM was installed. (Utilizing SSD cache can significantly improve performance.)
Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office
Maximum Users 1,800
Notes Multiple files were opened for testing and each file was edited by 30 users simultaneously.
CPU and RAM usage were both under 80% when the number of maximum users was reached.
For tested models with expandable memory, the maximum amount of RAM was installed.
Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station
Video Transcoding Group 1 - Type 1
Maximum Transcoding Channel Number 1 channel, 30 FPS @ 1080p(1920×1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1
Virtual Machine Manager
Recommended Virtual Machine Instances 4
Recommended Virtual DSM Number (Licenses required) 4 (including 1 Free License)
Notes The specifications vary depending on system configuration and memory size.
VPN Server
Maximum Connections 20
Τεχνικά Χαρακτηριστικά
ΚατασκευαστήςSynology
ΜοντέλοRackStation RS820RP+ (4-Bay NAS)
Part NumberRS820RP+
ΚατηγορίαNAS Chassis
Αριθμός Δίσκων4x 2.5"/3.5"
Υποστήριξη RAIDBasic
RAID 0
RAID 1
RAID 5
RAID 6
RAID 10
JBOD
RackmountRack
Θύρες Ethernet4x 1 Gbps
Συνδέσεις2x USB 3.0
1x eSATA
Μνήμη RAM2GB DDR4 non-ECC onboard memory (1 memory slot up to 16GB for a total of 18GB)
Εγγύηση3 Έτη
