Intel NUC Performance Kit - i3-1115G4 with 2.5¨ HDD Support
Χωρίς ΦΠΑ: - €
Πληροφορίες
Δόσεις
Άτοκες Δόσεις
Supported Operating Systems | Windows 10, 64-bit |
Board Number | NUC11PABi3 |
Board Form Factor | UCFF (4" x 4") |
Socket | Soldered-down BGA |
Internal Drive Form Factor | M.2 and 2.5" Drive |
# of Internal Drives Supported | 2 |
Lithography | 10 nm |
TDP | 40 W |
DC Input Voltage Supported | 19 VDC |
Processor Included | Intel® Core™ i3-1115G4 Processor (6M Cache, up to 4.10 GHz) |
Intel vPro® Platform Eligibility | No |
# of Cores | 2 |
# of Threads | 4 |
Max Turbo Frequency | 4.10 GHz |
Memory & Storage | |
Max Memory Size (dependent on memory type) | 64 GB |
Memory Types | DDR4-3200 1.2V SO-DIMM |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 51.2 GB/s |
Max # of DIMMs | 2 |
ECC Memory Supported | No |
Processor Graphics | |
Processor Graphics | Intel® UHD Graphics for 11th Gen Intel® Processors |
Integrated Graphics | Yes |
Graphics Output | HDMI 2.0a USB-C (DP1.4) MiniDP 1.4 |
# of Displays Supported | 4 |
Expansion Options | |
PCI Express Revision | Gen4 |
PCI Express Configurations | M.2 slot with PCIe X4 lanes |
Removable Memory Card Slot | SDXC with UHS-II support |
M.2 Card Slot (storage) | 22x80 |
I/O Specifications | |
# of USB Ports | 7 |
USB Configuration | 2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C) USB 2.0 USB 3.1 Gen2 via internal headers |
USB Revision | 2.0, 3.1 Gen2 |
USB 2.0 Configuration (External + Internal) | 0 + 1 |
USB 3.0 Configuration (External + Internal) | 2B 2F + 1 |
Total # of SATA Ports | 2 |
Max # of SATA 6.0 Gb/s Ports | 2 |
Audio (back channel + front channel) | 7.1 digital (HDMI mDP); L+R mic (F) |
Integrated LAN | Intel® Ethernet Controller i225-V |
Integrated Wireless | Intel® Wi-Fi 6 AX201 |
Integrated Bluetooth | Yes |
Consumer Infrared Rx Sensor | Yes |
Additional Headers | CEC, USB3.1, USB2.0, FRONT_PANEL, RGB |
# of Thunderbolt™ Ports | 2x Thunderbolt™ 3 |
Advanced Technologies | |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel vPro® Platform Eligibility | No |
TPM | No |
Intel® HD Audio Technology | Yes |
Intel® Rapid Storage Technology | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Platform Trust Technology (Intel® PTT) | Yes |
Security & Reliability | |
Intel® AES New Instructions | Yes |
HIGH SPEED PERFORMANCE FOR HOME AND OFFICE
Finish your work and then play arcade games, stream movies and music, and quick-charge phones with the ultra-responsive 11 Gen Intel® Performance NUC with support for up to 64 GB of high-speed DDR4 RAM. Panther Canyon is small enough to move around the office and house. These Mini PCs deliver outsized performance with a full range of i7, i5, and i3, 11th Gen Intel® Core(TM) processors and amazing Intel® Iris® Xe graphics.
FEATURE RICH FOR VERSATILITY
With its modern design and innovative features, the Panther Canyon is built for the new age of small-compute innovation. At home or on the road, connect to any screen and every peripheral with ten ports and slots. Combine this with Iris® Xe graphics, Thunderbolt(TM) 3, mini DisplayPort, and HDMI capability for the optimal visual experience. Talk to Amazon Alexa from across the room and multitask on up to four screens. The charging lid on some systems can even be used to quickly and wirelessly charge phones, earbuds, and other devices.
EFFICIENCY BY DESIGN
The Panther Canyon delivers a unique combination of commanding performance, immersive graphics, fast and flexible connectivity, and innovations like wireless charging, remote control, and voice control. Finally, the pint-sized, eye-catching, do-everything home and office computer has arrived.
- 11th Gen Intel® Core™ i3-1115G4
- Intel® UHD Graphics
- Dual channel DDR4-3200 SODIMMs max 64GB
- 1x M.2 SSD slot
- Intel® Wi-Fi 6 AX201 + Bluetooth 5
- Beam-forming, far-field, quad-mic array, with Alexa support
- 2x Thunderbolt 3 ports
- 3x USB 3.1 Gen2 ports
- 3.5mm front stereo headset
- SDXC slot
- 19V DC input
- 1x Mini DisplayPort 1.4 ports
- Intel® i225-V 10/100/1000/2500 Mbps RJ45 Ethernet
- 1x HDMI 2.0b
- Kensington lock (on opposite side)
Κατασκευαστής | Intel |
Μοντέλο | NUC Performance Kit - i3-1115G4 with 2.5¨ HDD Support |
Part Number | RNUC11PAHi30000 |
Κατηγορία | NUC / Brix |
Επεξεργαστής | Intel® Core™ i3 -1115G4 (Up to 4.10GHz Turbo Boost, 6MB Cache, 2 Cores - 4 Threads, 11th Gen Tiger Lake) |
Μνήμη RAM | Χωρίς Μνήμη RAM |
Κάρτα Γραφικών | Ενσωματωμένη - Intel UHD Graphics for 11th Gen Intel Processors |
Δίσκος | Χωρίς Δίσκο |
Υποδοχές Σκληρών Δίσκων | M.2 SSD and 2.5" HDD or SSD |
Λειτουργικό Σύστημα | Χωρίς Λειτουργικό |
Πρόσθετα Χαρακτηριστικά | SD Slot HDMI V 2.0a Mini DisplayPort V 1.4 Wi-Fi Intel Wi-Fi 6 AX201 Bluetooth Thunderbolt III USB Type-C M.2 Slot |
Εγγύηση | 3 Έτη |
