Intel NUC Pro Kit - i5-1135G7 with 2.5¨ HDD Support

Εξαντλημένο
-
Χωρίς ΦΠΑ: - €
Πληροφορίες
Κωδικός Msystems: 001-51554
Part Number: BNUC11TNHI50002
Εγγύηση: 3 Έτη

Παρακαλώ συμπληρώστε τον ΤΚ σας
Παρακαλώ επιλέξτε νομό
Παρακαλώ επιλέξτε πόλη

Με πιστωτική κάρτα Visa, Mastercard, American Express, Diners
Παρακάτω βλέπετε τις επιλογές για τις έντοκες δόσεις.
242,45 € / δόση = 484,90
162,37 € / δόση = 487,10
122,32 € / δόση = 489,26
98,28 € / δόση = 491,42
82,27 € / δόση = 493,62
70,83 € / δόση = 495,83
62,25 € / δόση = 498,03
55,58 € / δόση = 500,24
50,24 € / δόση = 502,44
45,88 € / δόση = 504,69
42,25 € / δόση = 506,94
39,17 € / δόση = 509,19
36,53 € / δόση = 511,44
34,25 € / δόση = 513,70
32,25 € / δόση = 515,99
30,49 € / δόση = 518,29
28,92 € / δόση = 520,59
27,52 € / δόση = 522,89
26,26 € / δόση = 525,23
25,12 € / δόση = 527,53
24,09 € / δόση = 529,88
23,14 € / δόση = 532,22
22,27 € / δόση = 534,57
21,48 € / δόση = 536,96
20,74 € / δόση = 539,30
20,06 € / δόση = 541,70
19,43 € / δόση = 544,09
18,85 € / δόση = 546,53
18,30 € / δόση = 548,92
17,79 € / δόση = 551,36
17,31 € / δόση = 553,80
16,86 € / δόση = 556,23
16,43 € / δόση = 558,67
16,03 € / δόση = 561,16
15,66 € / δόση = 563,64

Με πιστωτική κάρτα Visa, Mastercard
Δεν υπάρχει η δυνατότητα για άτοκες δόσεις με κάρτες American Express και Diners
234,50 € / δόση = 469,00
156,33 € / δόση = 469,00
117,25 € / δόση = 469,00
93,80 € / δόση = 469,00
78,17 € / δόση = 469,00

Πρόγραμμα δανείου από την Τράπεζα Πειραιώς
6 έως και 84 δόσεις
Σταθερό επιτόκιο 9,75% πλέον εισφ. 0,60%.
Facebook Twitter Email
Facebook Twitter Email
Περιγραφή
Supported Operating Systems Windows 10, 64-bit, Windows 10 IoT Enterprise, Red Hat Linux, Ubuntu 20.04 LTS
Board Number NUC11TNBi5
Board Form Factor UCFF (4" x 4")
Socket Soldered-down BGA
Internal Drive Form Factor M.2 and 2.5" Drive
# of Internal Drives Supported 3
TDP 28 W
DC Input Voltage Supported 12-24 VDC
Processor Included Intel® Core™ i5-1135G7 Processor (8M Cache, up to 4.20 GHz)
# of Cores 4
# of Threads 8
Max Turbo Frequency 4.20 GHz
Memory & Storage
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-3200 1.2V SO-DIMMs
Max # of Memory Channels 2
Max # of DIMMs 2
ECC Memory Supported  No
Processor Graphics
Processor Graphics  Intel® Iris® Xe Graphics
Integrated Graphics  Yes
Graphics Output Dual HDMI 2.0b w/HDMI CEC
Dual DP 1.4a via Type C
# of Displays Supported  4
Expansion Options
PCI Express Revision Gen 4 (m.2 22x80 slot); Gen 3 (otherwise)
PCI Express Configurations  PCIe x4 Gen 4: M.2 22x80 (key M)
PCIe x1 Gen 3: M.2 22x42 (key B)
PCIe x1: M.2 22x30 (key E)
M.2 Card Slot (wireless) 22x30 (E)
M.2 Card Slot (storage) 22x80 NVMe (M)
22x42 SATA (B)
I/O Specifications
# of USB Ports 4
USB Configuration Front: 2x USB 3.2
Rear: 2x USB 4 (type C),
1x USB 3.2,
1x USB 2.0
Internal: 1x USB 3.2 on m.2 22x42 (pins)
2x USB 2.0 (headers)
Total # of SATA Ports 1
Serial Port via Internal Header Yes
Integrated LAN Intel® Ethernet Controller i225-LM
Integrated Wireless Intel® Wi-Fi 6 AX201
Integrated Bluetooth Yes
Additional Headers Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby)
Internal 2x2 power connector
# of Thunderbolt™ Ports 1x Thunderbolt™ 4
1x Thunderbolt™ 3
Package Specifications
Chassis Dimensions 117 x 112 x 54 mm (LxWxH)
Advanced Technologies
Intel® Optane™ Memory Supported  No
Intel® Virtualization Technology for Directed I/O (VT-d)  Yes
Intel® ME Firmware Version 15
Intel® Virtualization Technology (VT-x)  Yes
Intel® Platform Trust Technology (Intel® PTT) Yes
Security & Reliability
Intel® AES New Instructions Yes

A LEAP FORWARD IN BUSINESS PERFORMANCE

Boundary-breaking performance is available with the latest 11th Gen Intel® Core™ i5 and i7 processors featuring Intel® Iris® Xe graphics and support for high-speed 3200 MHz DDR4 memory. Whether you’re creating a digital kiosk, deploying intelligent vending, or refreshing enterprise PCs, Tiger Canyon can get the job done easily. Select Tiger Canyon SKUs also feature Intel vPro® technology for remote manageability, hardware-enhanced security features, and platform stability to help businesses cut IT costs and boost uptime.

POWER FOR THE FUTURE OF BUSINESS

Every Intel NUC 11 Pro system can support one 8K or four 4K displays for digital signage, video conferencing, and other deployments. Operate Tiger Canyon in cluster of small form factor PCs. Businesses can also get more work done anytime, anyplace, with the latest wired and wireless options, including Intel® Wi-Fi 6 AX201, the fastest generation of Wi-Fi, and two ultra-fast Thunderbolt™ ports.

BUSINESS-CLASS REMOTE MANAGEABILITY

Tiger Canyon, built on Intel 11th Gen architecture, provides greater system performance over previous generations with advanced hyperthreading technologies driving faster speeds and enhanced graphics. Qualified for 24×7 operation and backed by a three-year warranty, Intel NUC 11 Pro Mini PCs, kits, and boards are small, powerful systems designed to meet today’s needs—and keep businesses running for years. With Intel® vPro™ technology you can help your customers get ahead of security threats. The built-in hardware-enhanced security means you can keep client data and credentials secure, and remote manageability is perfect for installations such as unattended digital kiosks and intelligent vending.

  1. 11th Gen Intel® Core™ i5-1135G7
  2. Intel® Iris™ Xe Graphics
  3. Dual channel DDR4-3200 SODIMMs max 64GB
  4. 2x M.2 SSD slots
  5. Intel® Wi-Fi 6 AX201
  6. 3x USB 3.2 Gen2 ports
  7. Kensington lock
  8. 12-24V DC input
  9. 2x Thunderbolt (DP 1.4a and USB 4)
  10. 2x HDMI 2.0b
  11. Intel® i225-LM 10/100/1000/2500 Mbps RJ45 Ethernet
  12. 1x USB 2.0 port
Τεχνικά Χαρακτηριστικά
ΚατασκευαστήςIntel
ΜοντέλοNUC Pro Kit - i5-1135G7 with 2.5¨ HDD Support
Part NumberBNUC11TNHI50002
ΚατηγορίαNUC / Brix
ΕπεξεργαστήςCore i5 -1135G7 (Turbo Boost up to 4.20GHz, 8MB Cache, 11th Gen Tiger Lake - 4 Cores / 8 Threads)
Κάρτα ΓραφικώνIntel Iris Graphics - Intel Iris Xe Graphics
ΔίσκοςΧωρίς Δίσκο
Υποδοχές Σκληρών ΔίσκωνM.2 SSD and 2.5" HDD or SSD
Λειτουργικό ΣύστημαΧωρίς Λειτουργικό
Πρόσθετα ΧαρακτηριστικάHDMI V 2.0b x2
Wi-Fi Intel Wi-Fi 6 AX201
Bluetooth
Thunderbolt III (Supports DisplayPort 1.4)
Thunderbolt 4 (Supports DisplayPort 1.4)
LAN - Intel® Ethernet Controller i225-LM
M.2 Slot
Εγγύηση3 Έτη
